Product description
Engine Type: 4-stroke, SOHC, 4-Valve
Displacement: 447.92 cc
Bore x Stroke: 89 x 72 mm
Cylinders: Single
Engine Cooling: Liquid
Fuel System: Keihin FCR-MX 39
Starting System: Electric starter / 4 Ah; Ignition: Kokusan digital
Front Suspension: hlins fully adjustable, twin A-arms
Front Travel: 10.2 in. (257 mm)
Front Brake Type: 7.08 in. (180 mm) floating WAVE discs, 4-piston fixed caliper x 2
Front Tires: 21 x7-10 in. MAXXIS Razor
Rear Suspension: hlins PDS mono-shock, fully adjustable, swingarm
Rear Travel: 10.4 in. (265 mm)
Rear Brake Type: 7.87 in. (200 mm) disc, single piston floating caliper
Rear Tires: 20 x11-9 in. MAXXIS Razor
Frame: Chromoly; Subframe: Aluminum 7020
Dry Weight: 351.1 lbs (163 kg)
Fuel Capacity: 3.54 gal (13.4 l)
Ground Clearance: Unloaded: 11.42 in. (290 mm)
Wheelbase: 50.39 in. (1280 mm)
Final Drive: 520 X-ring chain 5/8 x 1/4 in.
Transmission: 5-speed XC semi-close-ratio + reverse
