2009 Hyosung TE 450S
2009 Hyosung TE 450S pictures, prices, information, and specifications.
Model Type
Sport
MSRP
$4,999
Dealers
Warranty
12
Insurance
Generic Type (Primary)
Sport
Manufacturer Country
Japan
Introduction Year
2008
Manufacturer Recommend Minimum Age
16
Parent Company
Hyosung
Display Name
TE 450S
Year
2009
Make
Hyosung
Engine Type
Single-Cylinder
Cylinders
1
Engine Stroke
4-Stroke
Horsepower (bhp/kW)
52 / 38.8
Horsepower RPM
8500
Torque (Ft Lbs/Nm)
35.1 / 47.6
Torque RPM
7000
Cooling
Liquid
Valves
4
Valves Per Cylinder
4
Valve Configuration
DOHC
Bore (mm/in)
96 / 3.78
Stroke (mm/in)
62 / 2.44
Displacement (cc/ci)
449 / 27.4
Compression Ratio
12:1
Starter
Electric
Fuel Requirements
Regular
Fuel Type
Gas
Fuel Injector
No
Carburetor
Yes
Number Of Carburetors
1
Carburetion Type
Carburetor
Transmission Type
Manual
Number Of Speeds
5
Overdrive
No
Primary Drive (Rear Wheel)
Chain
Primary Drive (Engine / Transmission)
Chain
Reverse
Yes
Hi / Low Range
No
Wheels Composition
Steel
Tube / Tubeless
Tubeless
Front Tire Diameter (in)
21
Rear Tire Diameter (in)
20
Chromed
No
Front Tire Width
7
Front Wheel Diameter
10
Rear Tire Width
11
Rear Wheel Diameter
9
Front Tire (Full Spec)
21 X 7-10
Rear Tire (Full Spec)
20 X 11-9
Front Brake Type
Dual Hydraulic Disc
Front Brake Diameter (in/mm)
6.7 / 170
Rear Brake Type
Hydraulic Disc
Rear Brake Diameter (in/mm)
9.4 / 240
Linked Brake System Front to Rear
Standard
Front Suspension Type
Independent Double A-Arm
Front Travel (in/mm)
8.7 / 220
Front Adjustable Fork Pre-Load
Yes
Front Adjustable Rebound Damping
Yes
Front Central Suspension Strut
No
Steering Damper
No
Front Stabilizer Bar
No
Rear Suspension Type
Swing Arm
Rear Travel (in/mm)
9.4 / 240
Rear Adjustable Shock / Spring Pre-Load
Yes
Rear Adjustable Rebound Damping
Yes
Number Rear Shock Absorbers
1
Rear Suspension Material
Aluminum
Rear Stabilizer Bar
No
Air Adjustable
No
Steering Type
Manual
Steering Control
Handlebar
Length (ft)
5.94
Width (in/mm)
45.7 / 1160.8
Height (in/mm)
45.9 / 1165.9
Wheelbase (in/mm)
49.8 / 1264.9
Ground Clearance (in/mm)
11.4 / 289.6
Length (ft/ft)
5
Length (ft/in)
11.3
Dry Weight (lbs/kg)
467 / 211.8
Fuel Capacity (gal/l)
2.1 / 7.9
Engine Displacement to Weight (cc)
0.96
Seat Type
One-Piece
Adjustable
No
Seat Material
Vinyl
Seat Location
Driver
Folding
No
Seat Height (in/mm)
34.8 / 83.9
Number Of Seats
1
Frame
Steel
Body Material
Plastic
Hand Grips
Standard
Foot Peg Location
Driver
Adjustable
No
Hand Guards
No
Brush Guard
No
Light Guard
No
CV Boot Cover
No
Shock Cover
No
Front Fender
Standard
Rear Fender
Standard
Handlebars
Standard
Front Bumper
Standard
Rear Bumper
Standard
A-Arm Skid Plate (Front)
Yes
Bash Plate (Front)
Yes
Full Length Skid Plate
No
Digital Instrumentation
Standard
Trip Odometer
Standard
Speedometer
Standard
Temperature Warning Type
Light
Warranty (Months/Condition)
12 / Limited
Battery Warranty (Months)
0
Driveline Type
4X2
Number Of Driveline Modes
1
Rear Unlocking Differential
No
Rear Solid Axle
Yes
Headlight Mounts
Standard
Halogen Headlight (s)
Standard
Headlight (s)
Standard
Light Type
Halogen
Metallic
No
Decal Kit
Standard
