Product description
Engine Type: DOHC, four-stroke
Displacement: 695 cc
Bore x Stroke: 102.0 X 85.0 mm
Cylinders: 1
Engine Cooling: Liquid-cooled
Fuel System: Fuel Injection
Starting System: CDI
Front Suspension: Independent, double A-arm, oil-damped, five preload settings
Front Travel: 7.1 in.
Front Brake Type: Dual hydraulic disc
Front Tires: AT 25 x 8-12
Rear Suspension: Independent, double A-Arm, oil-damped, five preload settings
Rear Travel: 8.1 in.
Rear Brake Type: Sealed hydraulic disc
Rear Tires: AT 25 x 10-12
Frame: High-tensile steel frame
Dry Weight: 602 lbs.
Towing Capacity: Trailer Hitch
Fuel Capacity: 4.6 gal.
Ground Clearance: 10.2 in.
Machine Dimensions (LxWxH): 83.5 x 47.6 x 48.0
Wheelbase: 50.4 in.
Final Drive: Shaft drive
Transmission: V-belt CVT automatic with high/low range sub-transmission, 2WD/4WD/4WD front differential lock
Speedometer: Standard: LCD
Odometer: Standard: LCD
Lighting: 30W multi-reflector halogen headlights, 5/21W tail light and brake light, 40W multi-reflector, handlebar-mounted auxiliary light
Colors: Advantage Max-4 HDTM
